APC NetShelter Rack Automatic Transfer Switch 1U 20A – AP4452A
APC NetShelter Rack Automatic Transfer Switch 1U 20A – AP4452A
Regular price
$1,118.00 USD
Regular price
$1,350.00 USD
Sale price
$1,118.00 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
APC NetShelter Rack Automatic Transfer Switch – AP4452A
Ensure continuous power to your rack equipment with dual-input redundancy. The AP4452A automatically switches to a backup power source in milliseconds if the primary source fails – without interrupting connected equipment.
Technical Specifications
| Specification | Value |
|---|---|
| Form Factor | 1U Rack-Mount |
| Input Voltage | 120V AC |
| Input Connectors | 2x NEMA L5-20P |
| Max Input Current | 20A (16A derated) |
| Output Connectors | 10x NEMA 5-20R |
| Max Output Current | 16A |
| Frequency | 50/60 Hz |
| Switching Time | <8ms |
| Management Interface | Network (CLI / Web) |
| Weight | 9.70 lbs |
| Dimensions (L x W x H) | 17.00 x 9.30 x 1.75 in |
| Compliance | UL, FCC Class A, RoHS |
